1. What the Name Says: F4B-M-220

F4BM220 is a PTFE glass-cloth copper-clad laminate — polytetrafluoroethylene resin, woven glass reinforcement, electrodeposited copper foil. The name decomposes into three parts, and each part is a specification:

SegmentValueWhat it fixes
F4BPTFE glass-cloth CCLThe material family — PTFE resin on woven glass, the national-standard base name
MGlass-cloth reinforced gradeThe current-generation construction (no M = legacy predecessor, see below)
220Dielectric constant × 100Dk 2.20 ± 0.04 at 10 GHz — read it off the name, no datasheet needed

The same rule makes the whole family legible: F4BM255 is Dk 2.55, F4BM300 is Dk 3.00. Older drawings say F4B220 with no M — that is the predecessor of this exact grade and resolves to the current F4BM220. The full decode across all fifteen series of the family, including the RTF-copper and ceramic-filled branches, is in the complete model list, and the family-level view is in the F4B family map.

2. The Three Electrical Numbers

Three values carry almost all of the electrical decision, and each answers a different question:

ValueF4BM220The question it answersIn practice
Dk @10 GHz2.20 ± 0.04How big is the circuit?Sets trace width and wavelength; ±0.04 tolerance is what your impedance window buys
Df @10 GHz0.0010How much signal is lost per inch?28× lower dielectric loss than FR-4; the reason the material exists
TCDk−142 ppm/°CHow much does Dk move with temperature?Dk drifts 2.8 % over 200 K — invisible in most uses, critical in phase-matched arrays

A caution that parameter lists get backwards: the third number is often quoted as “stable under temperature fluctuations”. It is not, in the way RO3003 is stable — −142 ppm/°C is a large coefficient, comparable to RT/duroid 5880. For amplifiers and couplers the drift is irrelevant; for a phased-array feed it is a pointing error of roughly 24° per 100 mm at 10 GHz across a 200 K swing. Section 5 puts the temperature picture together.

3. What the Numbers Mean on a First Layout

For a designer touching the material for the first time, one worked example is worth more than the parameter table. On a 0.254 mm core — the most common thin F4BM220 build — a 50 Ω microstrip comes out at these numbers:

QuantityF4BM220 (Dk 2.20)FR-4 (Dk 4.4)Consequence
W/h for 50 Ω3.11≈1.90.79 mm trace on F4BM220 vs 0.48 mm on FR-4 — wider, more forgiving etch
Guided wavelength at 10 GHz21.9 mm≈14 mmSlower wave on FR-4; F4BM220 lines are electrically longer per mm
Dielectric loss at 10 GHz0.039 dB/in1.08 dB/inA 10-inch FR-4 run loses 10.8 dB; the same run on F4BM220 loses 0.4 dB

The width column surprises FR-4 designers in both directions: traces are wider (etch tolerance is a smaller fraction of width — good), but filters and couplers grow proportionally (space budget — plan for it). The impedance arithmetic behind the numbers, including what solder mask and etch tolerance do to the final value, is in the impedance control guide.

4. The Physical Data Sheet, Decoded

The mechanical and physical numbers decide whether the laminate survives fabrication and assembly, not whether the antenna radiates. The published figures for F4BM220:

PropertyValueWhat it means for your board
Thickness range0.1–12 mm (std. 0.254 / 0.508 / 1.0 mm)Thin cores for mmWave, thick cores for power handling; impedance scales with h
Panel sizes460×610, 914×1220 mm (max 1500×1000)Panel utilisation drives per-board laminate cost
Peel strength≥18 N/cm at room temperatureSurvives assembly, rework and wire bonding
Solder dip260 °C / 20 s, no blistering or delaminationStandard reflow and wave profiles are inside the envelope
Warpage≤0.03 mm/mm at 0.25 mm thicknessFlat enough for fixtures and connector seating on thin builds
Copper weights0.5–5.0 oz fabricablePower feeds and antenna patches on the same stack

Water absorption deserves its own sentence because datasheets disagree: published third-party data gives ≤0.08 % (24-hour immersion), while some sources quote 0.02 % for specific builds. Both numbers are far below the ~0.1 % class where moisture starts moving impedance, but the exact figure for your thickness should come from the supplier datasheet rather than from a marketing page.

5. Temperature: the Honest Version

Two temperature facts coexist for F4BM220, and an introduction that keeps only the flattering one sets up a bad surprise:

AspectNumberRead it as
Operating range−50 to +260 °CThe material survives automotive under-hood and soldering profiles
TCDk−142 ppm/°CDk falls 2.8 % over 200 K; phase shifts ≈24° per 100 mm at 10 GHz
Z-CTE240 ppm/°C (14× copper)A 1.6 mm board grows ≈83 µm in reflow; vias need ≤6:1 aspect ratio and ductile plating

The range says the laminate survives; the coefficients say what drifts while it survives. Electrically F4BM220 sits next to the best PTFE laminates — mechanically it must be manufactured like them: aspect-ratio limits, high-elongation copper, PTFE desmear chemistry. The full processing window is in the F4BM220 processing page.

6. What It Is Used For

At introductory level, the application list is short and the reasons are the three numbers from section 2:

ApplicationWhich number does the work
Base-station antennas, feed networksDf 0.0010 — loss stays low across long feeds
Couplers, dividers, phase shiftersDk 2.20 ± 0.04 — predictable geometry
Radar front-end and phased arraysDf for sensitivity — but check TCDk against the phase budget
Satcom and aerospace RF panels−50 to +260 °C range plus low moisture pickup

Which industry buys it for what, and why 2.20 rather than a higher rung of the ladder, is the subject of the F4BM220 industries page; the per-application electrical depth is in the specifications page.

7. Who Makes What: Laminate Maker vs Board Fabricator

A correction the old version of this page blurred: the laminate and the board come from different companies, and the distinction matters when something goes wrong. The F4BM220 laminate is produced by Wangling (旺灵), the materials manufacturer behind the F4B designation system. XCE PCB (Shenzhen Xincheng’er Electronics) is a PCB fabricator: it buys the laminate, and manufactures the finished circuit — drilling, PTFE desmear, plating, impedance control, hybrid pressing with FR-4, inspection to IPC-A-600G and IPC-6015.

Practically: datasheet questions (Dk tolerance on your thickness, water absorption, per-grade loss for the filled branches) go to the material datasheet; everything from stack-up review onward — impedance targets, via design for the 240 ppm/°C Z-CTE, solder-mask choice, yield — is fabricator work. For a first board, both questions usually arrive together, which is why the DFM review matters more here than on FR-4: testing and acceptance points are cheaper to agree before the panel is etched.

8. Ordering the First F4BM220 Board

The model number plus four fields makes an F4BM220 quote comparable; leaving any of them out invites a price for a different board:

FieldExampleWhy the name cannot carry it
Finished thickness0.254 mmSame grade ships 0.1–12 mm; impedance and drill windows follow h
Copper weight1 oz (35 µm base)Loss, etch tolerance and current all track copper
Impedance window50 Ω ± 10 % (±3 % coupon-verified)The tighter the window, the more the process proof costs
Build2-layer PTFE, or hybrid with FR-4Hybrid stacks need two press chemistries; quote differs structurally

Prototype lead time is 3–4 days with 24–72-hour expedite available, mass production 6–7 days — on F4BM220 those numbers hold only when the desmear chemistry and press route are already in the quote, which is the DFM pass again. If the first design mixes F4BM220 with FR-4 layers, read the F4B hybrid lamination guide before fixing the stack. And the reason FR-4 alone stops working at these frequencies, if that comparison is what brought you here, is in why standard FR-4 is not suitable.

9. Conclusion

For a first contact, F4BM220 reduces to three sentences. The name is the spec: PTFE glass-cloth laminate, current M grade, Dk 2.20 read straight off the number. The numbers are three questions: Dk sets geometry (0.79 mm for a 50 Ω line on 0.254 mm), Df sets loss (0.039 dB/inch at 10 GHz, 28 times better than FR-4), TCDk sets how much the phase drifts (2.8 % of Dk over 200 K — the one number to check against a phase budget). And an order is the name plus four fields: thickness, copper weight, impedance window, build.

XCE PCB fabricates F4BM220 boards against those fields: 2 to 72 layers, panels to 600×1200 mm, impedance ±10 % standard and ±3 % on coupon-verified builds, PTFE desmear and hybrid pressing in-house, samples in as fast as 24 hours, 5,000 m² of plant with 80+ engineers and over 10,000 high-frequency builds since 2009. Send the stack — or just the frequency and the space available — and the DFM pass comes back before anything is quoted.

Frequently Asked Questions

What does F4BM220 stand for?
PTFE glass-cloth copper-clad laminate (F4B), current glass-cloth-reinforced grade (M), with a dielectric constant of 2.20 ± 0.04 at 10 GHz — the number is Dk × 100. The same rule decodes the whole family: F4BM255 is Dk 2.55, F4BM300 is Dk 3.00.
Is F4BM220 the same as F4B220?
F4B220 is the legacy predecessor designation; F4BM220 is the current grade at the same Dk 2.20, with published TCDk and Z-CTE data and UL 94 V-0 rating. Old drawings calling out F4B220 resolve to F4BM220 — confirm thickness and copper weight from the drawing, not the name.
What trace width gives 50 ohms on F4BM220?
On a 0.254 mm core, the W/h ratio is 3.11, so a 50 Ω microstrip is about 0.79 mm wide. Wider than the 0.48 mm FR-4 equivalent, which makes etch tolerance a smaller fraction of the width — but filters and couplers grow proportionally, so budget the space.
What temperature range can F4BM220 handle, and what drifts?
The material operates from −50 to +260 °C and survives 260 °C solder dip. What drifts is Dk: TCDk is −142 ppm/°C, so Dk moves about 2.8 % over a 200 K excursion (≈24° of phase per 100 mm at 10 GHz), and the Z axis expands at 240 ppm/°C — 14 times copper — which is why vias need a 6:1 aspect-ratio limit and ductile plating.
Who manufactures F4BM220 — and who makes the board from it?
The laminate is made by Wangling (旺灵), the materials manufacturer behind the F4B designation system. XCE PCB is the board fabricator: it purchases the laminate and manufactures the finished PCB — drilling, PTFE desmear, plating, impedance control, hybrid pressing, IPC-A-600G/IPC-6015 inspection. Datasheet questions go to the material datasheet; everything from stack-up review onward is fabricator work.
What does an F4BM220 order need besides the model number?
Four fields: finished dielectric thickness (impedance and drill windows follow it), copper foil weight (loss and etch tolerance), the impedance window (±10 % standard, ±3 % coupon-verified), and the build (pure PTFE or hybrid with FR-4, which changes the press chemistry and the quote structure). Prototype lead time is 3–4 days, 24–72-hour expedite available.
