Layer: 4
Board Material: Isola
Board Thickness: 1.0mm
Surface Technology: Immersion Gold
Copper thickness: 0.5oz
Hole: Resin Plug Hole
Green Oil with White Letters

Number of layers: 4
Board Material: F4B M225
Board Thickness: 1.0 mm
Surface Technology Immersion Gold
Holes Resin Plug Holes
Soldermask Color: Brown
No Characters

Board Material: Rogers 5880
Plate Thickness: 1.1mm
Copper Thickness: 0.5oz
Surface Technology: iImmersion Gold
Hole: Resin Plug Hole
Soldermask Color: Matte Black
Character: White

Layers: Double-sided Board
Size: 32.1*76.6mm
Board Material: RO4003C
Board Thickness: 0.813mm
Copper Thickness: 1oz
No Solder Resist, No Character
Surface Process: OSP
Minimum Line Spacing: 4mil
Minimum Drilling: No Drilling

Layers: Double-sided
Size: 67.65*30mm
Board Thickness：1.0mm
Board Material: Rogers 4350B
Copper Thickness: 1oz
Gold Immersion Area: 8.3%
Soldermask Color: Green Oil
Character Color: White
Minimum Drilling: 0.25mm (240 Pieces)

Layer: 6
Board Thickness: 1mm
Surface Technology: Gold Immersion, Resin Plug Holes
Drilling: 1-2 and 5-6 are laser holes (0.1mm), 2-5 are mechanical holes
Layer Structure: FR4(high TG)+PPS1000-2M+Rogers TC350(0.508mm)+PPS1000-2M+FR4(high TG)
Outer Layer Copper 1OZ, Inner Layer 0.5OZ
