Taconic High-frequency PCB
Kico Hu
2024-11-13
No Comments
Layer: 2
Board Material: Taconic
Board thickness: 1.1mm
Surface Technology: Immersion Gold
Copper thickness: 0.5oz
No Solder Resist
Layer: 2
Board Material: Taconic
Board thickness: 1.1mm
Surface Technology: Immersion Gold
Copper thickness: 0.5oz
No Solder Resist
Layer: 4
Board Material: Isola
Board Thickness: 1.0mm
Surface Technology: Immersion Gold
Copper thickness: 0.5oz
Hole: Resin Plug Hole
Green Oil with White Letters
Number of layers: 4
Board Material: F4B M225
Board Thickness: 1.0 mm
Surface Technology Immersion Gold
Holes Resin Plug Holes
Soldermask Color: Brown
No Characters
Layer: 2
Board Material: F4B M220
Plate Thickness: 1.1mm
Surface Technology: Immersion Gold
Hole: Resin Plug Hole
Soldermask Color: Green
No Character
Layer: 2
Board Material: Rogers 4350B
Board Thickness: 1.2mm
Surface Technology: Immersion Gold
Hole: Resin Plug Hole
Solder Resist Color: White
No Character
Board Material: Rogers 5880
Plate Thickness: 1.1mm
Copper Thickness: 0.5oz
Surface Technology: iImmersion Gold
Hole: Resin Plug Hole
Soldermask Color: Matte Black
Character: White
Layers: Double-sided Board
Size: 32.1*76.6mm
Board Material: RO4003C
Board Thickness: 0.813mm
Copper Thickness: 1oz
No Solder Resist, No Character
Surface Process: OSP
Minimum Line Spacing: 4mil
Minimum Drilling: No Drilling
Layers: Double-sided
Size: 67.65*30mm
Board Thickness：1.0mm
Board Material: Rogers 4350B
Copper Thickness: 1oz
Gold Immersion Area: 8.3%
Soldermask Color: Green Oil
Character Color: White
Minimum Drilling: 0.25mm (240 Pieces)
Layer: 6
Board Thickness: 1mm
Surface Technology: Gold Immersion, Resin Plug Holes
Drilling: 1-2 and 5-6 are laser holes (0.1mm), 2-5 are mechanical holes
Layer Structure: FR4(high TG)+PPS1000-2M+Rogers TC350(0.508mm)+PPS1000-2M+FR4(high TG)
Outer Layer Copper 1OZ, Inner Layer 0.5OZ
Layers: 2
Board Thickness: 1.6mm
Board Material: FR4(KB6160)
Surface Technology: Immersion Gold 1U
Copper Thickness: 1oz
Green Oil White Letters
Board Material: RO4350B
Size: 217*100mm
Board Thickness: 1.52mm
Copper Thickness: 1oz
Soldermask Color: Blue
Character Color: White
Surface Process: Immersion Gold
Layers: 4
Board Material: 4350B+FR4
Board Thickness: 1mm
Surface Technology: Immersion Gold
Green Oil with White Characters
Layers: Double Panel
Size: 240*86mm
Board Material: Tecangli TLX-7
Board Thickness: 0.79mm (including copper thickness, final board thickness)
Copper Thickness: 1oz
Surface Process: Immersion Gold 2U
Layer: 4
Finished Board Thickness: 3.4mm
Size: 209*36mm
Process Requirement: Immersion Gold
Finished Copper Thickness: 1oz
Board Material: Rogers 4350B
Green Oil with White Characters
Layers: 4
Finished Board Thickness: 2.7mm
Size: 212*172mm
Process Requirements: Immersion Gold
Finished Copper Thickness: 1oz
Board material: Rogers 4350B
Green Oil With White Lettering
Layers: 6
Size: 110*73.6mm
Board Material: Rogers 3003+FR4
Plate Thickness: 1.5mm
Copper Thickness: 1oz
Surface Process: OSP
Minimum Drilling: 0.15mm
