1. How a F4B Part Number Is Read

Every designation in this catalog decomposes the same way, and reading it correctly answers three questions before any datasheet is opened: what the dielectric is, what the copper is, and what the dielectric constant is.

SegmentExampleMeaning
PrefixF4BPTFE (F4) glass-cloth copper-clad laminate; the national-standard base name
Branch letterM / ME / TMM = current glass-cloth grade; E = reverse-treated (RTF) copper foil; T = ceramic-filled dielectric
Number220Dielectric constant × 100, so F4BM220 = Dk 2.20 at 10 GHz
Extra suffix-2-A / SConstruction variants: −2-A = ceramic-film build; S = ultra-thin, ultra-fine glass fabric
No letter (legacy)F4B255Predecessor grade; superseded grade-for-grade by the M series

The number rule is the fastest triage tool in RF sourcing: the number is the Dk. F4BM220 is a Dk 2.20 laminate, WL-CT615 a Dk 6.15, F4BTMS1000 a Dk 10.0. Two caveats apply: the tolerance and Df behind the number differ by branch (section 2 to 4), and for the extended series outside the published ladder the per-grade loss data should be confirmed against the current datasheet rather than assumed. The family-level view of what each branch is for is in the F4B family map.

2. F4BM: the Nine-Grade Core Ladder

The F4BM series is the volume core of the catalog — PTFE plus woven glass cloth with electrodeposited copper, nine Dk grades from 2.17 to 3.00, full published electrical data:

ModelDk @10 GHzDf @10 GHzTCDk (ppm/°C)Z-CTE (ppm/°C)
F4BM2172.17 ± 0.040.0010−150240
F4BM2202.20 ± 0.040.0010−142240
F4BM2332.33 ± 0.040.0011−130205
F4BM2452.45 ± 0.050.0012−120187
F4BM2552.55 ± 0.050.0013−110173
F4BM2652.65 ± 0.050.0014−100142
F4BM2752.75 ± 0.050.0015−92112
F4BM2942.94 ± 0.060.0017−8598
F4BM3003.00 ± 0.060.0018−8095

UL 94 V-0 rating and water absorption at or below 0.08 % (F4BM220 confirmed data) hold across the ladder. Note the pattern the tolerance column shows: ±0.04 at the bottom of the Dk range loosens to ±0.06 at 3.00 — one more reason to climb only as high as the layout actually requires. The 2.20 grade, being the most specified, has its own page: F4BM220 specifications and impedance arithmetic.

3. F4BME: the Same Nine Grades on RTF Copper

F4BME217 through F4BME300 mirror the F4BM ladder one-for-one — same Dk, same Df, same temperature coefficients, same tolerance. The only physical difference is the foil: standard electrodeposited copper is replaced with reverse-treated (RTF) copper, bonded smooth-side to the dielectric.

That single change exists for one electrical reason: passive intermodulation. The flat copper-dielectric interface of an RTF foil lowers PIM in antenna feed networks, which is why F4BME is the base-station antenna branch and F4BM is everything else. Any source claiming F4BME has a different Df or a ceramic-filled dielectric is wrong — the foil types and their loss consequences are compared in the PCB copper foil guide.

4. F4BTM and F4BTME: the Ceramic-Filled Branch

The T branch adds ceramic filler to the PTFE glass-cloth system, extending the Dk range past 3.00 toward 3.5 and — because ceramic loading pulls the strongly negative PTFE temperature coefficient toward zero — improving TCDk. The published models:

SeriesModelsDk rangeDfCopper
F4BTM298, 300, 320, 3502.98–3.5from 0.0018Standard ED
F4BTME298, 300, 320, 3502.98–3.5from 0.0018RTF (E suffix = foil only)

The per-grade Df and TCDk values for the filled branch are not published in the same detail as the F4BM ladder; before a filled grade goes on a drawing, confirm the current datasheet with the supplier. The trade the branch makes is clear from the two columns it does publish: Dk above 3.0 buys smaller geometry, Df from 0.0018 costs about 80 % more dielectric loss per inch than F4BM220.

5. Legacy F4B Grades and Their Current Replacements

Older drawings still call out the unlettered F4B grades. They map straight onto the current ladder — same number, same Dk intent, newer construction and tolerance control:

Legacy modelCurrent replacementWhat changed
F4B220F4BM220M-grade construction; published TCDk/Z-CTE data; UL 94 V-0
F4B255F4BM255Same Dk 2.55; current grade carries ±0.05 tolerance on the published table
F4B265F4BM265Same Dk 2.65; successor grade on the current ladder

When a legacy number arrives on an RFQ, the substitution is grade-for-grade by number — confirm the thickness and copper weight from the drawing, not the name. First-time readers of the family usually meet it through the 2.20 grade: the F4BM220 introduction covers the naming and first-read parameters.

6. The Extended Series: Film Builds, Fine Glass, and Beyond PTFE

Beyond the four core branches, the catalog covers nine more series. The naming logic holds — prefix for the chemistry, number for the Dk where the ×100 rule applies — but the constructions diverge, and so does the data published for them:

SeriesConstructionModelsDk span (from numbering)
F4BM-2-APTFE glass cloth + ceramic film build255, 265, 294, 3002.55–3.00
F4BME-2-ASame, on RTF copper255, 265, 294, 3002.55–3.00
F4BTMSUltra-thin, ultra-fine glass fabric, ceramic-filled PTFE220, 233, 255, 265, 294, 300, 350, 430, 450, 615, 10002.20–10.0
TFAPTFE-ceramic composite dielectric294, 300, 615, 10202.94–10.2
TF / TF-1 / TF-2PTFE-ceramic composite dielectric CCLTF, TF-1, TF-2per datasheet
WL-CTOrganic polymer-ceramic, glass cloth CCL (non-PTFE)300, 330, 330Z, 338, 350, 440, 6153.00–6.15
WL-PP300 / WL-PP350Hydrocarbon-ceramic bonding sheets (prepreg)300, 350bonding layers, not CCL
WL-PP280-50N / 50HCeramic composite film bonding sheets280 (two variants)bonding layers, not CCL
TP / TP-1 / TP-2Microwave composite dielectric CCL (not F4B/PTFE glass cloth)TP, TP-1, TP-2per datasheet
F4B-N / F4B-T / TWH002PTFE glass-coated clothN, T, TWH002per datasheet

Three practical notes on this table. F4BTMS is the series most often garbled into “F4B TMS” in secondhand articles — it is one series, ultra-fine glass with ceramic fill, and it is the only one whose ladder reaches Dk 10. TP-2 belongs to the composite-dielectric branch, not to F4B — designs that list it as an F4B variant are misfiling it; the distinction is laid out in the TP-2 page. And the WL-PP entries are bonding materials, the companion layers that make F4B-to-FR-4 hybrid stacks possible — the press windows they enable are covered in the F4B hybrid lamination guide.

7. Reading a Part Number on a Drawing: What to Confirm Before Quoting

A part number names the dielectric; an order needs four more fields, and a quote that skips them is pricing a different board:

FieldExampleWhy it is not in the part number
Finished dielectric thickness0.254 mm, 0.508 mm, 1.5 mm…Every Dk grade ships in many thicknesses; impedance scales with h
Copper foil weight0.5 oz, 1 oz, 2 ozLoss and etch tolerance both track copper weight
Foil typeED vs RTF (the E branch)Determines PIM behavior; must be stated, not assumed
Cladded size / panelSheet format per stockingCutting plans and yield follow from it (see cutting considerations)

The thickness field deserves emphasis because it is the one the naming system cannot carry: the same F4BM220 at 0.127 mm and at 1.5 mm are different impedance problems, different drill problems, and different cutting plans — the handling rules are in the substrate cutting guide.

3 Things the Old List Got Wrong

The previous version of this page was the catalog in its raw form — fifteen numbered lines and a company blurb. Three specific problems were fixed:

No naming rules. The list gave F4B255 and F4BM255 side by side with no indication that one is the predecessor of the other; sections 1 and 5 now carry the decode and the substitution map. No construction data. Fifteen series were indistinguishable; the extended-series table now separates PTFE glass cloth, ceramic-film builds, composite dielectrics, non-PTFE polymer systems and bonding materials — five different procurement decisions that a flat list collapsed into one. A stale company claim. “15 years of expertise” was hardcoded in the text; XCE PCB has been building high-frequency boards since 2009, and dates that age with the page belong in the footer, not the copy.

Where a series sits in a full material decision — against Rogers grades, against cost targets, against a loss budget — is a framework question, and the material selection guide walks it. The processing consequences of the ceramic-filled and composite-film branches (desmear chemistry, press windows) are treated grade-specifically in the F4BM220 processing page.

9. Conclusion

The F4B catalog is one naming system across fifteen series, and once the segments are decoded the list stops being a catalog and becomes a menu: the branch letters say what the dielectric and the foil are made of, the number says the Dk, and the series table says what data is published and what must be confirmed. The F4BM nine-grade ladder (Dk 2.17–3.00, Df 0.0010–0.0018) is the documented core; F4BME duplicates it on RTF copper for PIM; F4BTM and the F4BTMS fine-glass series extend it toward Dk 10 for compact geometry; the WL and TP/TF/TFA series cover composite and non-PTFE systems with bonding companions for hybrid stacks.

XCE PCB fabricates all of them: 2 to 72 layers, panels to 600×1200 mm, impedance ±10 % standard with coupon-verified tighter windows, PTFE desmear and hybrid press capability in-house, samples in as fast as 24 hours, 5,000 m² of plant with 80+ engineers and over 10,000 high-frequency builds since 2009, inspected to IPC-A-600G and IPC-6015. Send the part number — or just the Dk, thickness and frequency — and the series can be confirmed before anything is quoted.

Frequently Asked Questions

What does the number in an F4B model name mean?
The dielectric constant times 100, referenced at 10 GHz. F4BM220 is Dk 2.20 ± 0.04, F4BM255 is 2.55, WL-CT615 is 6.15, F4BTMS1000 is 10.0. The letters around the number carry the construction: M = glass-cloth reinforced grade, E = reverse-treated copper foil, T = ceramic-filled dielectric.
What is the difference between F4BM and F4BME models?
The copper foil only. F4BME grades use reverse-treated (RTF) copper bonded smooth-side to the dielectric, which lowers passive intermodulation in antenna feeds. The Dk, Df, TCDk and Z-CTE values are identical grade for grade — F4BME217 through F4BME300 mirror the F4BM ladder exactly.
Are F4B255 and F4BM255 the same material?
F4B255 is the legacy predecessor and F4BM255 is the current grade at the same Dk 2.55. Old drawings calling out F4B255 (or F4B220, F4B265) resolve grade-for-grade to the M-series equivalent; confirm thickness and copper weight from the drawing itself.
Which F4B series goes above Dk 3.5?
F4BTMS, the ultra-thin ultra-fine glass fabric ceramic-filled series, spans Dk 2.20 to 10.0 (models 220 through 1000), and the TFA PTFE-ceramic composite series reaches 10.2. These are the compact-geometry grades; per-grade loss and temperature data are thinner than the F4BM ladder documentation, so confirm against the current datasheet before committing.
Is TP-2 an F4B model?
No. TP, TP-1 and TP-2 belong to the microwave composite-dielectric branch of the catalog, a different chemistry from the PTFE glass-cloth F4B system. Listings that file TP-2 under F4B variants are misfiling it; the material distinction and its Dk range are covered on the TP-2 page.
What must an F4B order specify beyond the model number?
Four fields the name cannot carry: finished dielectric thickness (impedance scales with it), copper foil weight (loss and etch tolerance), foil type (ED vs RTF, which sets PIM behavior), and panel size (cutting plan and yield). A quote based on the model number alone is pricing a different board.
